HM series

HM series

Submersible electropumps
The ultimate pumps for waste water and purification equipment, with single channel closed impeller.

Submersible electric pump HM, thanks to their tough construction and the single channel closed impeller, that offers reliability against clogging and features wide through sections and a good resistance to wear, low mechanical action on the fluid, high hydraulic efficiency, is particularly suitable for clean water, water containing solid and fibrous solids, cloacal water, sewage and sludge.

Is possible the submersible fixed installation with the automatic coupling foot or the mobile installation with base support.

Motor asynchronous squirrel cage type in dielectric anti-oxide oil bath, protectin degree IP 68 and insulation class F. Single-phase feeding: motor protector and capacitor in box control. Three-phase feeding: with compulsory protection to be provided by the user.

Motor housing cast iron GG 25, shaft stainless steel AISI 420, electric cable neoprene H07RN8-F, bolt A2 class AISI 304, O.rings nitrile. Shaft sealing by two mechanical seals mounted in series in ecologic oil chamber. Seal types applied to the motor side on ceramic/graphite and seal types applied to the wet end side on silicon carbide.

Conductivity sensor and thermal probes on request.

Example of installation

Permanent installation with automatic coupling system

TYPEFlow rateHeadFree passagePump deliveryMotor powerDWGData sheetSpare parts listInfo
HM 65/102max 750 l/min - 45 m3/hmax 18 mdiam. 40 mmDN 652 HP - 1.5 KW
HM 65/103max 1000 l/min - 60 m3/hmax 22 mdiam. 40 mmDN 653 HP - 2.2 KW
HM 66/111max 1100 l/min - 66 m3/hmax 20 mdiam. 45 mmDN 654 HP - 3 KW
HM 80/111max 1200 l/min - 72 m3/hmax 18 mdiam. 45 mmDN 804 HP - 3 KW
HM 66/112max 1400 l/min - 84 m3/hmax 24 mdiam. 45 mmDN 655.5 HP - 4.1 KW
HM 80/112max 1500 l/min - 90 m3/hmax 22 mdiam. 45 mmDN 805.5 HP - 4.1 KW
HM 81/114max 2230 l/min - 133.8 m3/hmax 32 mdiam. 55 mmDN 8010 HP - 7.5 KW
